Bare Endless Rod™

The Superior Continuous
Sucker Rod

Endless Rod™ is a continuous sucker rod with only two connections, designed to perform across a wide range of well conditions. Its continuous design supports improved reliability and reduced intervention compared to conventional jointed sucker rod systems.

Lifting Solutions is an industry leading provider of continuous rod products and services. From research and development through design and precision manufacturing, Endless Rod products are built to outperform the market.

Reduce Intervention Of Your Well

Frequent well interventions increase operating costs and disrupt production. Endless Rod is designed to reduce intervention frequency over the life cycle of the well by minimizing common failure points associated with jointed sucker rod systems.

With only two connections in the entire rod string, Endless Rod helps improve long‑term system reliability.

Features And Benefits

Endless Rod is designed to support improved operational efficiency through its continuous construction. Key benefits include reduced overall intervention frequency, lower production costs through increased pump life and reduced energy usage, and decreased tubing wear and rod parts.

The continuous design minimizes pressure losses around couplings by increasing annular space, decreases string weight by up to 12 percent, and lowers power and equipment requirements, allowing for the use of smaller pumping units at the surface. These factors also contribute to increased service efficiency.

Metallurgies & Sizes

Endless Rod is available in the same sizes and similar metallurgies as conventional sucker rod. Product selection is based on load requirements and fluid properties to best suit the application.

Lifting Solutions’ technical application specialists work directly with operators to determine the optimal Endless Rod design for each well. The product is available from 3/4" inch to the largest size available on the market, 1‑3/16", and is offered in seven grades across regular, mid, and high‑strength options.
